ABB DO810数字输出模块3BSE008510R1

ABB DO810 3BSE008510R1数字输出模块概述

这款数字输出模块拥有16个隔离通道，每个通道可输出24V直流电，电流达0.5A，并具备短路保护功能。为确保兼容性，需配合相应的终端单元进行集成。

产品参数详解

• 产品型号：3BSE008510R1

• ABB型号标识：DO810

• 目录描述：DO810数字输出模块，支持24V、16通道

• 详细规格：分为两组各8个通道的隔离设计，单通道电流0.5A，具备短路防护功能。建议使用TU810、TU812、TU814、TU830或TU833模块终端单元。

技术性能指标

• 绝缘隔离：按组隔离接地

• 负载电阻：0.4Ω

• 电流限制：具备短路防护的限流输出

• 最大现场电缆长度：600米（656码）

• 额定绝缘电压：50V

• 绝缘测试电压：500V交流电

• 功耗：典型值2.1瓦

• 模块总线+5V电流消耗：80mA

诊断与监控功能

前端LED指示灯提供故障（F）、运行（R）、警告（W）、输出状态保护（OSP）及1-16通道状态显示。支持过程电压监控和模块状态指示，包括错误和警告提示。

环境认证与安全标准

• 符合CE认证要求

• 安全标准：EN 61010-1、UL 61010-1、EN 61010-2-201、UL 61010-2-201

• 危险区域认证：C1 Div 2 cULus、C1 Zone 2 cULus、ATEX Zone 2

• 船舶认证：ABS、BV、DNV、LR等机构认可

工作环境要求

• 运行温度范围：0至+55℃（+32至+131℉），批准温度为+5至+55℃

• 存储温度范围：-40至+70℃（-40至+158℉）

• 污染等级：2级（IEC 60664-1标准）

• 防腐蚀等级：ISA-S71.04 G3级标准

湿度与安装条件

相对湿度要求为5%至95%（无冷凝），最大环境温度55℃（131℉）。垂直安装于紧凑型MTU时，环境温度上限为40℃（104℉）。

核心特点与优势分析

This module stands out with its robust design featuring 16 output channels that handle up to 500mA per channel at 24V DC, ensuring reliable performance even in demanding industrial settings. The dual isolation groups enhance process voltage supervision, while the visual status indicators provide immediate feedback on operational conditions.

Safety Features That Set It Apart

The built-in overcurrent protection safeguards against ground faults and voltages up to 30V, complemented by over-voltage and over-temperature safeguards that maintain consistent reliability. Output State Protection (OSP) adds an extra layer of security by automatically setting outputs to a predetermined state upon detecting errors.

Sustainable Performance Under Varied Conditions

This module demonstrates exceptional adaptability across extreme temperature ranges and humidity levels, making it ideal for harsh industrial environments. The corrosion protection and wide operating temperature range ensure longevity even in challenging conditions.

Certifications That Build Confidence

The comprehensive certification portfolio, including CE mark and approvals from major maritime authorities like ABS and BV, underscores its global compatibility and reliability in critical applications.

User-Friendly Diagnostics for Seamless Maintenance

The intuitive diagnostic system with front LED indicators simplifies troubleshooting by providing clear visual cues about module status, channel conditions, and operational warnings, reducing downtime significantly.
