Emerson KJ3208X1-BA2 13P0105X012 Isolation Card

Emerson KJ3208X1-BA2 Isolation Card Product Overview

Emerson's KJ3208X1-BA2 isolation card is designed for industrial control systems to provide robust signal isolation and processing. It excels in harsh industrial environments, shielding against electrical noise, surges, and ground loops to ensure accurate data transmission. Its advanced isolation technology not only protects sensitive equipment from damage, but also significantly reduces signal interference and provides a solid guarantee for system integrity.

Technical Specifications

• Model: KJ3208X1-BA2

• Product Type: Isolation Card

• Local bus power supply: 12VDC, rated current 150mA

• Field circuit parameters: 60VDC, rated current of 1A per channel

• Operating temperature range: -40°C to +70°C

• Shock resistance: 10g half-sine wave for 11 milliseconds

• Vibration resistance: 1mm peak at 2 to 13.2 Hz, 0.7 g acceleration from 13.2 to 150 Hz

• Environmental standards: meet the requirements of ISA-S71.04-1985 G3 air pollutants

• Relative humidity range: 5% to 95% without condensation

Precautions for installation and use

Before disassembling or connecting this device, the field power supply (either via the field terminal or via the carrier bus) must be disconnected. It is strictly forbidden to plug and unplug the equipment in the state of system power-on. For non-spark field circuits, the power supply must be cut off prior to mating, including fused terminal blocks. The product adopts a rotary positioning system to ensure the compatibility of the I/O card and the terminal block after installation, and ensure that the positioning key of the terminal block matches the matching I/O card when using.

Product features and application advantages

The KJ3208X1-BA2 isolation card adopts a high-density integrated design, which can maintain long-term stable operation under harsh working conditions. Its compact form factor allows for easy retrofitting of existing control systems and enables seamless integration without the need for extensive adjustments. By providing a robust barrier against electrical interference, it significantly improves the overall stability of the system and ensures minimal disruption to critical data transmission. As an indispensable core component of an automation system, it optimizes the operational efficiency and reliability of complex control systems.

Related ancillary product reference

• Emerson KJ2201X1-BA1 logic solver module

• Emerson KJ3202X1-BA1 DeltaV discrete output card

• Emerson KJ4001X1-JA1 Terminal Interface Module

• Emerson KJ3002X1-BC1 analog input card

• Emerson PROFIBUS terminal interface block

• Emerson Delta V IS Terminal Interface Block

Technical Support Notes

The KJ3208X1-BA2 model is a proven solution in Emerson's product line. For models that have been discontinued or are difficult to procure, it is advisable to prioritize obtaining alternatives from official sources. This product information is for technical reference purposes only.
